Introduction
ESCOR™ 5020 resin is primarilo intended for extrusion coating and coextrusion coating . It has very good achesion to polar substrates, aluminum foil, metalized films, paper, iron, steel, and glass.
lt offers excellent balance of adhesion onto substrates and interlayer achesion with coextruded LDPE and EVA material.
Main Grades
| Resin Properties | Typical Value ( English ) | Typical Value ( SI ) | Test Based On |
| Density | 0.933 g/cm3 | 0.933 g/cm3 | ASTM D1505 |
| Melt Index 2 ( 190℃/2.16 kg ) | 8.3 g/10 min | 8.3 g/10 min | ASTM D1238 |
| Acrylic Acid Content | 7.5 wt% | 7.5 wt% | ExxonMobil Method |
| Peak Melting Temperature | 210 ℉ | 99 ℃ | ExxonMobil Method |
Draw Down Constant output at 35 rpm, 536℉（280℃） | 160 m/min | 160 m/min | ExxonMobil Method |
Neck-in 82 ft/min(25 m/min), Constant output at | 2.4 in | 7.1 cm | ExxonMobil Method |
164 ft/min(50 m/min), Constant output at | 1.5 in | 3.9 cm | |
328 ft/min(100 m/min), Constant output at | 1.3 in | 3.2 cm |
Application
Cable Shielding
Coextrusion Coating
Cosmetic Packaging
Extrusion Coating
Extrusion Lamination
Food Packaging
Hygiene Packaging
Lami Tubes
Liquid Packaging
Parameters
Minimum Order Quantity: | 25kg |
Price: | $2-$5 |
Packaging Details: | 25kg/bag |
Delivery Time: | 3-5 working days to departure port |
Payment Terms: | TT/LC |
Supply Ability: | 1000MT/Month |
