Introduction
PRIMACOR™ 1430 Copolymer is an ethylene acrylic acid copolymer that provides good sealability, hot tack and excellent adhesion to polar (foil, ylon, etc.) materials. It also provides excellent toughness, clarity and tear resistance.
PRIMACOR™ 1430 Copolymer exhibits:
· Adhesive layer of sealant layer in flexible packaging structures
· For blown or cast film extrusion
· Used where adhesion to nylon or foil is desired
Parameters
| Nominal Value (English) | Nominal Value (SI) | Test Method | ||
Resin | Density | 0.930 g/cm3 | 0.930 g/cm3 | ASTM D792 ISO 1183 |
Melt Index (2.16 kg @190℃) | 5.0 g/10min | 5.0 g/10min | ASTM D1238 | |
| Comonomer Content | 9.7 % | 9.7 % | SK Method | |
| Vicat Softening Temperature | 169 ℉ | 76.1 ℃ | ASTM D1525 ISO 306 | |
| Melting Temperature (DSC) | 205 ℉ | 96.1 ℃ | SK Method | |
Mechanical | Tensile Strength at Yield | 1110 psi | 7.93 MPa | ASTM D638 |
Tensile Strength at Break | 2830 psi | 19.5 MPa | ASTM D638 ISO 527-2 | |
| Tensile Elongation at Break (Compression Molded) | 580 % | 580 % | ASTM D638 ISO 527-2 | |
Film Properties | Film Thickness | 2.0 mil | 50.8 μm | ASTM D374 |
| Haze | 4.0 % | 4.0 % | ASTM D100 ISO 14782 | |
| Gloss (45°) | 74 | 74 | ASTM D2457 | |
Elmendorf Tear Strength MD Elmendorf Tear Strength TD | 470 g 730 g | 470 g 730 g | ASTM D1922 ISO 6383-2 | |
Tensile Strength at Yield MD Tensile Strength at Yield TD | 1510 psi 1480 psi | 10.4 MPa 10.2 MPa | ASTM D882 ISO 527-3 | |
Tensile Strength at Break MD Tensile Strength at Break TD | 4430 psi 4490 psi | 30.6 MPa 31.0 MPa | ASTM D882 ISO 527-3 | |
Tensile Elongation at Break MD Tensile Elongation at Break TD | 420 % 470 % | 420 % 470 % | ASTM D882 ISO 527-3 | |
Extrusion Condition 3 | · Screw Size: 2.5 in. (63.5 mm); 30:1 L/D; Single Flight with Maddock Mixer · Die Gap: 40 mil (1.0 mm) · Die Diameter: 6 in. (152.4 mm) · Melt Temperature: 385 ℉ (196 ℃) · Output: 6 lb/hr/in. of Die Circumference (1.07 kg/hr/cm of Die Circumference) · Blow-up Ratio: 2.5:1 · Frost Line Height: 29 in. (737 mm) | |||
1 Comonomer content measured by a SK proprietary method that has equivalent accuracy as compared to ASTM D 4094.
2 20 in/min (510 mm/min)
3 Equipment used to process this resin should be constructed of corrosion resistant materials. Dies and adapters are recommended to be stainless steels and/or duplex chrome or nickel plated.
Application
· Flexible packaging laminates
· Liquid packaging board laminates
Extrusion Notes
Equipment used to process this resin should be constructed of corrosion resistant materials. Dies and adapters are
recommended to be stainless and/or duplex chrome or nickel plated.
Notes
These are typical values and are not be construed as specifications. The physical properties are highly dependent on the
manufacturing conditions. So customers should confirm performances by their own tests.
