Introduction
Exact 9061 is an ethylene butene copolymer produced using
ExxonMobil's proprietary metallocene catalyst technology.
This resin iscompatible with polyolefins like polypropylene (PP), polyethylene (PE)and ethylene-vinyl acetate copolymer resin (EVA).
Parameters
| General | Avalability 1 | Asia Pacific | ||
| Revision Date | 04/01/2017 | |||
| Nominal Value (English) | Nominal Value (SI) | Test Based On | ||
Physical | Density 2 | 0.863 g/cm3 | 0.863 g/cm3 | ExxonMobil Method |
Melt Index (190℃/2.16 kg ) | 0.5 g/10min | 0.5 g/10min | ExxonMobil Method | |
| Hardness | Durometer Hardness (Shore A ) | 60 | 60 | ASTM D2240 |
| Mechanical | FlexuralMdiulus -1% Secant | 1160 psi | 7.98 MPa | ASTM D790 |
| Elastomers | Tensile Strss at 100% | 299 psi | 2.06 MPa | ASTM D412 |
| Tensile Strength at Break | 416 psi | 2.87 MPa | ASTM D412 | |
| Elongation at Break | 510 % | 510% | ASTM D412 | |
| Thermal | Vicat Softening Temperature | 111 °F | 43.8 ℃ | ExxonMobil Method |
| Peak Melting Temperature | 99 °F | 37 ℃ | ExxonMobil Method | |
| Crystallization Peak, Tc | 64 °F | 18 ℃ | ExxonMobil Method | |
Glass Transition Tg | -72 °F | -58 ℃ | ExxonMobil Method | |
Notes
Typical propeties: these are not to be construed as specifications.
1 Product may not be available in one or more countries in the identified Availability regions. Please contact your Sales Representative for complete Country Availability.
2 Property results are displayed in conventional unit of measure.
Application
Injection molded industrial and consumer durable goods
Impact modification of TPO
Features
EVA foam modification.
PP/TPO modification.- Low density.
Low crystallinity.. Free flowing pellets.
Parameters
Minimum Order Quantity: | 25kg |
Price: | $1.5-$3 |
Packaging Details: | 25kg/bag |
Delivery Time: | 3-5 working days to departure port |
Payment Terms: | TT/LC |
Supply Ability: | 1000MT/Month |
