Introduction
Radel R-5800 is a high melt flow grade of Radel polyphenylsulfone (PPSU). It is especially well-suited for parts requiring long flow length with thin walls. Radel resins offer exceptional hydrolytic stability and toughness superior to other commercially-available, high-temperature engineering resins. They also offer high deflection temperatures and outstanding resistance to environmental stress cracking. Radel polymers are inherently flame retardant, provide excellent thermal stability and possess good electrical properties.
Main Grades
| Physical | Test Method | Data | Unit |
| Density | ASTM D792 | 1.29 | g/cm3 |
| Shrinkage rate flow | ASTM D995 | 0.7 | % |
| Water absorption rate 23℃ 24hr | ASTM D570 | 0.37 | % |
| Melt Index 365 ℃ 5kg | ASTM D1238 | 24 | g/10min |
| Mechanical | Test Method | Data | Unit |
| Stretch film quantity 23℃ | ASTM D638 | 2340 | MPa |
| Tensile strength | ASTM D638 | 69.6 | MPa |
| Elongation rate | ASTM D638 | 7.2 | % |
| Bending strength | ASTM D790 | 91 | MPa |
| Bending modulus | ASTM D790 | 2410 | MPa |
| Cantilever beam notch impact | ASTM D256 | 690 | J/m |
Features
High HDT of 207°C (405°F)
Superior toughness and impact strength
Exceptional long-term hydrolytic stability
Better chemical resistance than PSU and PEI
Withstands over 1,000 cycles of steam sterilization without any significant loss of properties
Inherently flame retardant
Transparent
Colorable
Parameters
Minimum Order Quantity: | 25kg |
Price: | $1.8-$3.2 |
Packaging Details: | 25kg/bag |
Delivery Time: | 3-5 working days to departure port |
Payment Terms: | TT/LC |
Supply Ability: | 1000MT/Month |
